ZoHD Nano Talon EVO PNP Plane

EVO Improvements

• Wing dihedral has been eliminated in favor of a straight wing, which makes the Nano Talon much easier to fly in wind.
• Since the wing is now straight, it allows for a traditional wing spar joiner for added strength, rather than the older plastic joiner.
• A plastic belly protector is included to help keep it looking like new.
• Finger grooves have been added to improve launching grip.
• A traditional multirotor style motor has been chosen to make props easier to find than the older, proprietary version.
• The top canopy has been cut to allow for easy GPS mounting.
• The battery tray is now stronger and includes CG lines to keep battery placement consistent.

• EPP molded wing with built-in Carbon Fiber spars for reinforcement.
• Detachable main wing and tail wing for easy transport, and easy to change wing with a simple plug.
• The main wing is connected to the fuselage by a buckle, will be disconnect and release during a crash.
• “NACA” air-intake in nose and air-outlet in the tail for better cooling on FPV gear.
• Extra rooms in canopy and cabin for FPV gear, bottom hatch provide bonus rooms for more FPV equipment

• Brand Name: ZOHD
• Item Name: Nano Talon
• Wingspan: 860mm/33.85in
• Length: 570mm/22.44in
• Rudder: Yes (V-tail)
• Flap: No
• Aileron: Yes
• Flying Weight: ~360g (without FPV gear)
• Material: Crash Resistable EPP
• Weight: 700g
• CG: 3.5cm from the wing leading edge (marked under the wing)
• Color: White + Black
• Motor: ZOHD 2204 1870KV BL
• Motor Shaft Diameter: 5mm
• ESC: 30A W/1A BEC(XT60 connector)
• Servos: 3pcs 8g digital servo
• Propeller: 6×3 Inch
• Recommended Battery: 3S 1300-2200mAh with XT60 connector
• Flying speed: 12 to 90km/h

• 1x Nano Talon Airframe
• 1x Pre-assembled with Motor, ESC, Servos and Hardware.

Note: The nano talon no longer comes with the basic flight controller.
