STROBON V2 Navigation Light (GREEN) With Wire

STROBON Lights are the most powerful navigation lights on the model market for years.

Now, configurable for 5 different patterns!

1.Strobe  (Legendary Strobon v1 strobe effect. 3 fast flashes like xenon wing tip flash lights)

2.Blink (Simulates belly or tail lights. Continuous ON/OFF)

3.Heartbeat (standard beacon light pattern, ramp up/ramp down/off)

4.Rotating Beacon (perfect simulation of rolling beacons. ramp up/flash/ramp down/off)

5.Static (you can use it as landing headlights or static wing-tip lights)

It allows 2 different working modes;

• RC Controlled Mode: Plug it on your RC receiver’s any channel for RC mode, then you can enable/disable it over selected servo channel. Each Strobon counts the servo signals. So, you can plug more than one Strobon to the same RC channel to synchronize them.  (check the schematic below)
• Standalone Mode: Power it with directly from the battery (3.5-6v) it works on Standalone mode and works continuously.

​​Specifications

• Supply Voltage: 3.5 – 6 volt
• Current Consumption per hour  @5V
• Strobe: 60mA (1A when flashing)
• Blink: 70mA (150ma ON)
• Heartbeat: 120mA
• Rolling Beacon : 170mA (1A when flashing)
• Static: 140mA
• Diameter: 21.5mm
• Height: 6mm
• Screw Holes: 1.5mm diameter & 18mm distance
• Weight: 1.50 gram without wires
• Wire Length: 30cm

PATTERN SELECTION

All you need a piece of wire or a tweezer to change the pattern.
Connect two small pads of the Strobon v2 board while it’s working (it will not change the pattern when it’s OFF)
It will stop working when you connect these pins and jump to next pattern when you release the connection.
That’s all.

SCHEMATIC for SYNCRONIZED & RC CONTROLLED MODE

SCHEMATIC for STAND ALONE MODE
